| Output |
NL (No Lamp) |
LED20W |
| Total Lumens |
|
35 |
| Input Voltage |
10 to 15v |
11 to 15v |
| Input Power |
|
1.2W |
| VA (Use this number to size the transformer) |
|
1.7W |
| Lumens per Watt (Efficacy) |
|
30 |
| CRI (Ra) |
|
81 |
| Dimming |
PWM, Phase** |
Phase* |
| Luxor Compatibility |
|
|
| ZD Option |
|
Use Luxor Cube (LCM-LV) |
| Minimum Rated Life (Hrs, L70) |
|
33,000 Hrs |
**For optimal performance, use trailing edge phase cut dimmer.
